Kayat SRX Series Single Roll Bundler
Request More Information ›Texwrap's Kayat SRX series is a single roll bundler product platform. The platform can wrap loose product, product arriving in trays, and in 2024 it will be able to pack loose product in trays to wrap in film. The SRX uses bottom overlap technology for strong seals and the ability to showcase printed film graphics.
Designed to handle a wide variety of packaged food and beverage products, the SRX uses a single roll of clear or printed film, with speeds up to 60 cycles per minute. The SRX series has a robust, industrial design and provides easy access for operation and maintenance.
Features & Specs
- Toolless Adjustable Wrap Bar Assembly - Easily adjust wrap zone for package height with no change parts
- Easy Access Film Feed & Cut -Slide out film feed and cut assembly for easy maintenance
- Uses Clear or Print Registered Film
- State-of-the-Art Air Flow Control - Easily adjust air flow to create the most appealing appearance on the end product
- Updated Allen-Bradley controls package including predictive maintenance flags for common wear parts
- Dual roll film mandrels with manual splice - Minimizes roll to roll changeover time
SRX-CTP- Designed for tray packing loose product and shrink bundling with either printed or clear film.
Performance specifications of the Kayat SRX-CTP include:
- Minimum package size:
- 3” height
- 7.25” width (across the machine)
- 6” length (direction of flow)
- Minimum Blank Size:
- 25” width
- 19” length
- 3” tray wall height
- Maximum package size:
- 12” height
- 19” width (across the machine)
- 12.7” length (direction of flow)
- Maximum Blank Size:
- 25” width
- 19” length
- 3” tray wall height
- Speed: up to 60 cycles per minute
- Film width: 29” maximum
- Film diameter: 20” maximum
- Film types: clear or print-registered
- Construction: heavy-duty welded tubular steel standard; optional corrosion resistant construction for wipe-down environments
- Orientation: right- or left-handed available
- Magazine Capacity: Approximately 600 blanks (b-flute)
- Glue System: Nordson
SRX-CUF- Designed to shrink bundle loose products in film with no supporting pad or tray. Will accommodate either print registered or clear film.
Performance specifications of the Kayat SRX-CUF include:
- Minimum package size:
- 3” height
- 6” width (across the machine)
- 5” length (direction of flow
- Maximum package size:
- 12” height
- 20” width (across the machine)
- 12” length (direction of flow)
- Speed: up to 60 cycles per minute
- Film width: 30” maximum
- Film diameter: 20” maximum
- Film types: clear or print-registered
- Construction: heavy-duty welded tubular steel standard; optional corrosion resistant construction for wipe-down environments
- Orientation: right- or left-handed available
Side infeed bundling systems are versatile for diverse applications, including single products and multipacks. These machines are designed for a variety of a industries.
Texwrap offers a full range of in-line shrink bundlers for various applications, providing functional packaging solutions with options for print registered bundling for enhanced product presentation.
SRX-CTF - Designed to shrink bundle products already in trays with either printed or clear film.
Performance specifications of the Kayat SRX-CTF include:
- Minimum package size:
- 3” height
- 6” width (across the machine)
- 5” length (direction of flow
- Maximum package size:
- 12” height
- 20” width (across the machine)
- 12” length (direction of flow)
- Speed: up to 60 cycles per minute
- Film width: 30” maximum
- Film diameter: 20” maximum
- Film types: clear or print-registered
- Construction: heavy-duty welded tubular steel standard; optional corrosion resistant construction for wipe-down environments
- Orientation: right- or left-handed available
Side infeed bundling systems are versatile for diverse applications, including single products and multipacks. These machines are designed for a variety of a industries.
Texwrap offers a full range of in-line shrink bundlers for various applications, providing functional packaging solutions with options for print registered bundling for enhanced product presentation.
SRX-LTF - Designed to shrink bundle products already in trays with either printed or clear film.
Performance specifications of the Kayat SRX-LTF include:
- Minimum package size:
- 3” height
- 6” width (across the machine)
- 5” length (direction of flow
- Maximum package size:
- 12” height
- 20” width (across the machine)
- 12” length (direction of flow)
- Speed: up to 35 cycles per minute
- Film width: 30” maximum
- Film diameter: 20” maximum
- Single chamber tunnel
- Film types: clear or print-registered
- Construction: heavy-duty welded tubular steel standard; optional corrosion resistant construction for wipe-down environments
- Orientation: right- or left-handed available
Side infeed bundling systems are versatile for diverse applications, including single products and multipacks. These machines are designed for a variety of a industries.
Texwrap offers a full range of in-line shrink bundlers for various applications, providing functional packaging solutions with options for print registered bundling for enhanced product presentation.
